Product Name |
MasterBox NR600 |
Product Number |
MCB-NR600-KG5N-S00 (MasterBox NR600 with ODD) |
Exterior Color |
Black |
Materials ñ Body |
Steel, Plastic |
Materials ñ Windowed Side Panel |
Tempered Glass |
Dimensions |
478 (L) x 209 (W) x 473 (H) mm |
Motherboard Support |
Mini-ITX, Micro-ATX, ATX |
Expansion Slots |
7 |
5.25? Drive Bays |
N/A (MasterBox NR600 without ODD) |
1 (MasterBox NR600 with ODD) |
3.5? HDD Drive Bays |
4 |
2.5? SSD Drive Bays |
5 |
I/O Panel ñ USB Ports |
USB 3.0 x 2 |
I/O Panel ñ Audio In / Out |
1x 3.5mm Headset Jack (Audio Mic) |
Pre-installed Fan(s) ñ Front |
120mm x 1 |
Pre-installed Fan(s) ñ Rear |
120mm x 1 |
Fan Support ñ Front |
140mm x 2 / 120mm x 3 (MasterBox NR600 without ODD) |
140mm x 2/ 120mm x 2 (MasterBox NR600 with ODD) |
Fan Support ñ Top |
140mm x 2 / 120mm x 2 |
Fan Support ñ Rear |
120mm x 1 |
Radiator Support ñ Front |
280 / 240 / 140 / 120mm (MasterBox NR600 with ODD) |
Radiator Support ñ Top |
240mm (with ODD removed) / 120mm (MasterBox NR600 with ODD) (35mm max motherboard component height) |
Radiator Support ñ Rear |
120mm x 1 |
Clearance ñ CPU Cooler |
166mm / 6.54? |
Clearance ñ Power Supply |
180mm / 7.08? |
Clearance ñ Graphics Card |
410mm / 16.14? |
Cable Routing ñ Behind MB Tray |
20~28mm / 0.78~1.10? |
Dust Filters |
Top, Bottom |
Power Supply Support |
Bottom Mount, ATX |
